SOL-702

Solitine / UPS

SOL-702

Solitine SOL-702 Premium Mini DC UPS

Key Features
  • 12000mAh high-capacity lithium-ion battery with 36W max output
  • Selectable multi-voltage outputs: 5V, 9V, 12V, 15V, 24V DC + USB & Type-C
  • Supports Router, ONU, IP Camera & other DC devices simultaneously
  • Intelligent protections, silent fanless operation, auto-start & 1 Year Warranty
Brand Solitine
Category UPS
Model SOL-702
Availability In Stock
General
UPS Type Mini DC UPS (Lithium Battery Backup)
Color White
Power
Capacity 12000mAh
Rated Power 36W Max
Input Voltage 90-264V AC, 50-60Hz
Output Voltage Selectable: 5V, 9V, 12V, 15V, 24V DC
Output Frequency 50-60Hz (Pass-through)
Waveform Type Pure DC Output
Transfer Time Instantaneous (0 ms – Seamless switch)
Efficiency High efficiency (typical >85%)
Battery
Battery Type Built-in Lithium-ion (High-quality 21700 cells)
Battery Capacity 12000mAh
Battery Quantity Integrated (non-removable)
Backup Time Up to 4–8+ hours (depends on load — e.g., ~5-6 hours for Router + ONU)
Battery Voltage Internal Lithium nominal
Interface
AC Output Port None (DC UPS)
DC Output Port Multiple selectable DC ports (e.g., 9V/2A, 12V/2A etc.)
USB Port Yes (5V/2.4A or 5V/3A)
PoE Output Supported via polarity (some listings mention +4.5/-7.8 pins)
Connector Type DC ports + USB + Type-C (Smart Detect in some variants)
LED Indicator Yes (Battery level + Status LEDs)
Power Button Yes
Protection
Overload Protection Yes
Short Circuit Protection Yes
Overcharge Protection Yes
Surge Protection Yes
Overheat Protection Yes (Microprocessor controlled)
Features
Auto Restart Yes (Auto Start When Plugged In)
Cold Start Yes
AVR Support Not applicable (DC UPS)
Silent Mode Yes (Fanless silent operation)
Smart Charging Yes (Microprocessor controlled)
Physical
Dimensions 178 × 158 × 38 mm
Weight Approx. 550–700g
Material ABS Plastic
Warranty & Support
Warranty 1 Year Official Warranty
